The ideal instrument for your ultrasonic immersion tank or in-line inspection needs, featuring Phased Array technology alongside FMC/TFM advancements.
MAIN CHARACTERISTICS
Configuration: 64/128 Up to 64/256 channels
Communication Link: PWI at 100mm/s for 25mm thickness
LAN - (Useful sustained UT Data Flow 100 MB/s)
Size: 64/128 : 225x130x43 mm - 8.86x5.12x1.69 in
Weight: 64/128 : < 1.3 Kg / 3.75 lb - 64/256 : < 2 Kg / 4.41 lb
PERFORMANCE
Introducing the most compact and versatile rugged Phased Array device available today. Weighing just 1.2 kg, the Explorer is designed to meet the demands of your toughest applications. Its compact design, IP 67 rating, and easy mounting options make it ideal for integration into automated inspection systems, scanners, or robots.
The Explorer excels in any environment, delivering customized tools that exceed your expectations.
PERFECT FOR INDUSTRIAL APPLICATIONS
Technologies
-
Advanced Imaging Techniques
-
Air-Coupled Ultrasonic Testing
-
FMC/TFM
-
Phased Array Ultrasonic Testing
Applications
-
Robot application
-
Corrosion Inspection
-
Field Inspection
-
Weld Inspection
-
Composite Inspection
-
Inline Inspection
-
Research
Industries
-
Power generation
-
Oil & gas
-
Metallurgy
-
Automotive
-
Robotics
-
Railways
-
Aerospace
SPECIFICATIONS
-
Phased Array with DDF and Zone focus
-
FMC/TFM, PWI and many more
-
Standard probe connector
-
Very Rugged: IP 65 and IP 68 Rated
-
Battery Kit in option
-
In-Line (manufacturing)
-
On-Scanner
-
Field inspection
-
Immersion Tank
-
Gantry
